Model: ECOO Label Modular 330
Feature
1 Modular production process collocation meets complex requirements for label printing.
2 Combined structure, can be flexibly configured according to the actual production process.
3 Coating, Printing, V0061rnishing, Foil-stamping, One-click production.
4 High precision printing quality.
5 A cost-effective digital printer for label printing.
Technical data
| ECOO Label Modular 330 |
| Model | Ecoo Label Modular 330 |
| Printing Technology | Piezoelectric Inkjet | | Print Method | Roll to Roll, One -Side | | Color Configuration | Support up to 8 colors | | Number Of Channels | 8 | | Maximum Speed | 50m/min(CMYK); 25 m/min(CMYK+W) | | Resolution | 600x600 dpi/600 x1200 dpi | | Ink Type | UV Ink | | Curing Method | UV LED + Mercury lamp | | Media Width | 150-350mm | | Maximum Print Width | 324mm | | Media Thickness | 50-400um | | Media Type | PET, BOPP, PE, BOPA PP, Coated paper, Synthetic paper, Art paper, etc | | Maximum Media Roll Diameter | 700 mm | | Power supply | 380V | | Power | 30kw | | Compressed air | >6.5MPa | | Air consumption | >10L/min | | Operating environment | Temperature: 20℃-27℃, Humidity: 40%-70% relative humidity | | Skew Adjustment System | yes | | Electrostatic Dust Removal | yes | | Water Cooling System | yes | | Coating Unit | optional | | Digital Varnishing | optional | | Cold Foil Stamping | optional | | Hot Foil Stamping | optional | | Visual inspection | optional | |
| |
After Sales Service
All of our technicians have over 10-20 years experience.
Rich experience in installation, repair, and maintenance overseas.
After-sales staff Whatsapp/Wechat online 24/7.
Guarantee to provide after-sales service for any machine for its whole user life.
Packing & Service
Certificate
FAQ
1. What are your main products?
We Ecoographix is a specialized supplier of printing machines and consumables. We cover both digital printing and offset printing,
including prepress, pressroom and post press, focusing on packaging printing and book printing.
We have hundreds of users all over the world. We bring forward top quality of Chinese printing products to meet diversified printing requirements.
2. Where is your factory?
Our sale office is in Hangzhou, one hour by train away from Shanghai. Our factories are in Shanghai, Wenzhou, Suzhou and Nanyang.
3. What is your warranty?
One year for machine and printing head if use our ink. One year for machine only if do not use our ink.
4. What is the Lead Time?
Usually 30 days, and we will try our best to meet your demands.
5. What about the Installation and after-sales technician support?
Our engineer can go to help the installation and provide the necessary training. The buyer should take the round air plane tickets and service charge
and the local accommodation cost. Any problems or questions, we will be at your disposal 7x24 hours.
